主要参数：
| 型号 Model |
YD-WP4000 |
TD-WP6000 |
YD-WP12000 |
YD-WP36000 |
| 生产能力capacity(BPH) | 3000-5000 | 6000-9000 | 10000-15000 | 24000-36000 |
| 加热温度temperature(C) | 37-45 | 37-45 | 37-45 | 37-45 |
| 冷却时间cooling time(min) | 12-15min | 12-15min | 12-15min | 12-15min |
| 输送带线速度corveying speed | 100-550 | 100-550 | 100-550 | 100-550 |
| 网带宽度width of chain(m) | 1.22 | 1.22 | 1.22 | 1.22 |
| 蒸汽主管压力steam pressure(Mpa) | <0.4 | <0.4 | <0.4 | <0.4 |
| 循环水量water consumption(mvh) | 6 | 9 | 15 | 28 |
| 蒸汽耗用量steam consumption(kg/h) | 80 | 120 | 250 | 280 |
| 电机功率motor power(kw) | 6 | 7.55 | 8.6 | 18 |
| 外形尺寸outline dimension(mm) | 6200×1500×1700 | 15800×1500×1700 | 15800×1800×1700 | 22000×800×1700 |
| 重量weight(kg) | 2500 | 3200 | 4300 | 5600 |
